Arcfox Alpha S

The Arcfox Alpha S is a new generation of intelligent luxury electric sedan under the ARCFOX brand. Positioned as a mid-to-large-sized car, it offers two powertrain options and three different versions with varying ranges. Featuring a high-strength lightweight steel-aluminum hybrid body and a third-generation battery system, the ARCFOX Alpha S also offers the Arcfox Alpha S Pioneer Edition, equipped with three lidar sensors and numerous other sensors for autonomous driving in urban environments.

Range500-723KM
Power (peak)160-473KW
Battery capacity74.5KWH
Vehicle TypeSedans
CHARGE(10-80%)25minutes

Introduction

The dimensions of the Arcfox Alpha S are 4980×1960×1599mm (length x width x height), with a wheelbase of 2915mm, front track of 1660mm, and rear track of 1640mm. The car can accommodate 5 people.
The Arcfox Alpha S delivers a maximum horsepower of 643Ps, maximum power of 473kW, and maximum torque of 655N.m.
The Arcfox Alpha S utilizes a ternary lithium battery with an energy capacity of 74.55kWh, supporting fast charging that can reach 80% in as little as 15 minutes. It achieves a pure electric range of 500km (NEDC) or 525km (CLTC).

Highlighted Features

Extended True Range of 708km
Equipped with a high-energy density battery pack of 194Wh/kg and a propulsion system efficiency exceeding 93.5%, the Arcfox Alpha S achieves an exceptional range of 708km. It boasts the longest range among current mass-produced vehicles from new carmakers, addressing consumer concerns regarding charging difficulty and limited range. With a design focused on reducing the center of gravity, it achieves a minimum drag coefficient of 0.25 and accelerates from 0 to 100km/h in 4.2 seconds.
a Pilot Advanced Driver-Assistance System
The a Pilot advanced driver-assistance system enables Level 2 assisted driving. It incorporates features such as active safety warnings, active braking, and lane centering assist. In addition to automatic parking assist, it can also remotely move the vehicle smartly. By pressing the button behind the gear lever, the automatic parking assist function can be activated. The parking mode can be selected via the touch screen. The system will plan the route on its own, and the steering wheel will be controlled by the system.
Handling and Driving Experience
The unique advantages of electric vehicles result in rapid and smooth acceleration, providing a continuous and stable torque output during the driving process. Furthermore, the Arcfox Alpha S is equipped with an intelligent suspension system that automatically adjusts according to different road conditions and driving modes, delivering a comfortable and stable driving experience.

Parameters

Basic

Level	Full-Size Car
Energy Type	Electric
Sale Time	2023-05-19
Manufacturer	ARCFOX
NEDC Range [Km]	500
Country Of Origin	China

Size

Body Structure	5-Door 5-Seat HatchBack
Curb Weight [Kg]	2115
LengthWidthHeight [Mm]	498019601599
Wheelbase [Mm]	2915
Front Tire Specification	● 245/45 R20
Rear Tire Specification	● 245/45 R20

Power

Motor Type	Front Ac Asynchronous Motor Rear Permanent Magnet Synchronous Motor
Motor Max Power (Kw)	473
Motor Total Torque [N·M]	655
Battery Capacity [Kwh]	74.5
Official 0-100Km/H Acceleration [s]	3.5
Drive Form	Dual Motor Four-Wheel Drive

Battery

Battery Type	Ternary Lithium Battery
Battery Brand	CATL
DC Charging Time [Min]	15
AC Charge Time[H]	6.5
Power Consumption[Kwh/100Km]	17

Video

FAQ

How about the intelligent technology and safety features of the Arcfox Alpha S?

The ARCFOX Alpha S is equipped with a comprehensive range of intelligent technology and safety features. These include intelligent driver assistance systems, automatic parking functionality, blind-spot monitoring, etc., offering convenience and a safe driving experience for drivers. Additionally, the Arcfox Alpha S supports remote control and cloud connectivity, enabling remote monitoring and control of the vehicle through a mobile app.
